SEPS LED PIT Light are used for Wall recessed fitting lights for factory, railway workshop lighting purposes, PIT Lights are more energy-efficient, more environment-friendly and more illuminating as compared to regular lights. Providing our pit light with a good lighting to ensure a safe working environment for your machines. Their transparent lens give a wider dispersion of light, covering maximum areas.
| Details | SEPS- PIT LIGHT-24W |
| Input Power | 24Watt |
| Input Voltage | 24v AC/DC |
| Operating Voltage | 24vAC OR DC |
| Power Factor | More than 0.95 Test method as per IS 16104 standard |
| Colour Temperature | 5500K to 6500K |
| CRI | More than 70 |
| THD | Below 10% |
| Beam Angle | Beam 120 - 180 |
| Led Luminous Output | 110 ~ 140LM/W |
| LED Make | Osram |
| LED | High bright white power LED shall be use in the luminaries and wattage of LED above 0.50watt to 3watt |
| LED Life | More than 50000hrs |
| LED junction temperature | As per LM 80 Test Re |
| LED Life | More than 50000hrs |
| Luminaries Efficiency | Above 85% |
| Luminaries lumens/watt | 120LM/watt |
| Luminaries Lumens O/P | Upto 2880lm |
| Optics | Transperant PC lens for light direction and better light illuminity. |
| Housing | Aluminium Die Casting with powder coated body with aluminium heat sink with tuffend glass cover |
| Protection Cover | MS powder coated cover with MS hard net cover for damage protection from hard object |
| PCB | Good design Metal Core Pcb |
| Operating Temperature | (-30 deg to 70 deg centigrade) |
| Mounting arrangement | Recessed and surface wall mounted arrangement |
| LED Driver | Constant Current and variable voltage Test Method as per IS 16104 standard |
| Driver Protection | Short Circuit. Over Load Over Voltage and Over Heat Protection |
| IP Protection | Ip66 |
| Safety Standard | As per IS Standard, LM 80, LM79 |
| Surge protect | up to 4kva |
| Certifications | BIS, ISO, CE, ROHS, LM80, LM79, IP |
| Approval | Approved from Railways |
